12CBM Conrete Mixer Trucks

Concrete mixer truck used to transport concrete for construction. The concrete mixer truck can be charged with dry materials and water, with the mixing occurring during transport. This type of truck is equipped with a cylindrical mixer drum to carry the mixed concrete. Concrete mixer truck makes appearance of the vehicle modeling unique and high quality concrete mixer trucks have compact and reasonable structure.

The mixer drum will always be rotated during transport to ensure that the concrete carried does not freeze. After the concrete has been transported, the inside of the mixing drum is usually rinsed with water to prevent the hardened concrete from occupying space, and the capacity of the mixing drum is reduced. The tank material of the concrete mixer truck adopts special wear-resistant steel plate so as to fully guarantee the wear-resistance of the tank. Tank welding of the concrete mixer truck uses a special tank tooling fixture, with the use of automatic welding machine welding paint completely in accordance. The quality of the industry-leading level. Mixer tank capacity from 3m³ to 16m³.

Advantage
Specifications

The advantage of 12cbm Concrete Mixer truck

1. Italy famous brand PMP reducer
2. Imported original hydraulic pump and motor
3. Rational structure, safe and comfortable driving cab design
4. Excellent engine power, low oil consumption
5. High intensity drum material

The specification of 12cbm Concrete Mixer truck

Description	Concrete mixer truck
Drive Model	6X4
Vehicle Main Dimensions	Dimensions(L x W x H)mm		9017×2500×3970
	Wheelbase (mm)		3800+1350
	Overhang (front/rear) (mm)		1500/2520
	Wheel track (front/rear) (mm)		2027/1850/1850
	Approach/Departure angle(°)		30/12
Weight in KGS	Curb Weight		14050
	GVW.		25000
Max. driving speed(km/h)			75
Engine	Model		ISLe340 30
	Type		4-stroke direct injection, 6-cylinder in-line with water cooling, turbo-charging and inter-cooling
	Horse Power(HP)		340HP
	engine capacity		8900
	Emission standard		Euro III
Gearbox	10 forwards & 1 reverse
Clutch	Reinforced diaphragm clutch
Steering Gear	Power steering, hydraulic steering with power assistance
Fuel tank (L)	300
Tire	12.00R20 Radial tire, 11 pieces including one spare tire
axle load	7000/18000
Brakes	Service brake: dual circuit compressed air brake Parking brake(emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust valve brake
Mixer drum
Capacity（m³)		10-12m³
Material		Q235 carbon steel
Thickness		16mm
Water Supply Patterns		Air Pressure
Tilt(°)		11°-13°
Rotation Speed(r/m)		0-18
Material Discharging Speed		3(M3/min)
Material Remaining Ratio		≤0.6%
