4X2 Dongfeng 5CBM Fuel Tank Truck

Specification of 5cbm Fuel Tanker Truck

Condition

4 X 2

Chassis

Brand

Dongfeng

Curb weight(kg)

3755

Wheelbase(mm)

3300

Loading weight(kg)

3415,3350

Dimension(mm)

5990×1960×2400

Approach/departure angle(°)

19/14

Front/rear overhang(mm)

1032/1658

Wheel track(front/rear)(mm)

1586/1530

Max driving speed(km/h)

80

Axle load(kg)

2920/4380

Tire

Quantity

6

Specification

7.00-16

Cab

2-3 passengers allowed

Engine

Brand

Chaoyang,CY4102-C3C

Fuel type

Diesel

Displacement(ml)

3856

Max Power(kw)

88

Max Horsepower(hp)

120

Rated speed(rpm)

2800

Cylinder number

4

Intake form

Vertical straight line,water cooling,four stroke, supercharged medium cooling.

Emission standard

EuroⅢ

Upper

Tanker

Tanker material

Q235 Carbon steel

Tanker capacity(cbm)

5

Thickness（mm）

5-6

Tanker shape

Ellipse (as customer’s requirement)

Computer tax control refueling

1

Accessories

Manhole

1

Breathing valve

1

Oil pump

1

Front exhaust pipe

1

Filling gun

1

Anti wave plate

1-3

Lifting guardrail

1

Static wire plate

2

Fire extinguisher

2

Dispensing system

1.Filling system is controlleddigitally withcomputer tax controlling fuel dispenser.

2.Safety equipment has anti wave plate, ladder, static wire plate and fire extinguisher.

3.Various design can be selected, including shape,color and accessories.
